In stock
ATP360VL-9
3HP 9" WHEEL VERTICAL GRINDER
6,000 RPM Free Speed
Features
- Permanent mold casting
- High Performance 4-Vane Rotor
- Synthetic Rotor Blades
- Safety Lock-off Lever Throttle
Specifications
| Rated hp | 3 |
|---|---|
| Rated kW | 2.2 |
| Throttle Type | Lever |
| Spindle Output in | 5/8 - 11 |
| Wheel Diameter in | 9 |
| Wheel Guard Size in | 9 |
| Wheel Type & Thickness | 27 & 28 x 1/4" |
| Overall Length - in | 12.4375 |
| Overall Length mm | 316 |
| Side to Center in | 8.25 |
| Side to Center mm | 210 |
| Height to Flange Bottom in | 6.88 |
| Height to Flange Bottom mm | 175 |
| Air Inlet NPT in | 1/2" |
| Weight - lb | 10.75 |
| Weight kg | 4.88 |
| Hose ID in | 0.75 |
| Hose ID mm | 19 |
| Exhaust Direction | SIDE |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 55 |
| Air Consumption l/min | 1550 |
