Out of stock
ATP7560PT-RR
3/4" SQUARE DRIVE PISTOL GRIP IMPACT WRENCH
Features
- Two jaw clutch transfers high power
- Three piece housing for ease of repair
- Steel clutch housing
- Great for hard and soft draw applications
- Integral muffler for noise reduction
Specifications
| Working Torque ft-lb | 560 |
|---|---|
| Working Torque Nm | 760 |
| Max Torque ft-lb | 1000 |
| Max Torque Nm | 1356 |
| Tool Duty Rating | Super Duty |
| Handle Type | Pistol |
| Throttle Type | Trigger |
| Drive Size - in | 3/4 |
| Impact Mechanism / Clutch Type | Two Jaw |
| Socket Retainer | Ring Retainer |
| Housing Construction | 3 Piece |
| Length - in | 7.60 |
| Length mm | 193 |
| Weight - lb | 11.6 |
| Weight kg | 5.20 |
| Air Inlet NPT in | 3/8 |
| Min Hose ID in | 1/2 |
| Min Hose ID mm | 13 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 35 |
| Air Consumption l/min | 991 |
| OEM | Chicago Pneumatic |
| Comparable OEM Model | CP6060-SASAR |
