Out of stock
ATP1520EI-5S
#5 SPLINE DRIVE GRIP HANDLE INSIDE TRIGGER IMPACT WRENCH
Features
- Two jaw clutch transfers high power
- Steel clutch housing
- Great for hard and soft draw applications
- Integral muffler for noise reduction
- Three piece housing for ease of repair
Specifications
| Working Torque ft-lb | 2500 |
|---|---|
| Working Torque Nm | 3400 |
| Max Torque ft-lb | 3000 |
| Max Torque Nm | 4067 |
| Tool Duty Rating | Super Duty |
| Handle Type | Grip |
| Throttle Type | Inside Trigger |
| Drive Size Spline | 5 |
| Impact Mechanism / Clutch Type | Two Jaw |
| Socket Retainer | Button |
| Housing Construction | 3 Piece |
| Length - in | 14.70 |
| Length mm | 373 |
| Weight - lb | 33 |
| Weight kg | 14.90 |
| Air Inlet NPT in | 1/2 |
| Min Hose ID in | 3/4 |
| Min Hose ID mm | 19 |
| Performance Pressure PSIG | 90 |
| Performance Pressure Bar | 6.2 |
| Air Consumption cfm | 70 |
| Air Consumption l/min | 1,982 |
| OEM | Chicago Pneumatic |
| Comparable OEM Model | CP6120-PASEL |
